Electro Acoustic Specification
- Nominal Chassis Diameter 12/305 in/mm
- Maximal Power 1400 Watts
- RMS Power 700 Watts
- Impedance 8 ohm
- Resonance(natural) Frequency 64 Hz
- Frequency Response 64-3500 Hz
- Sensitivity(1 W/1 m) 98 dB
- Voice Coil Diameter 3.5"/89.5mm
- Windling material PIALR
- Magnet 136 Oz
Thiele Small Parameters
- FS Hz 64 Hz
- Vas 40.3 L
- RE Ohms 5.6 ohm
- Qms 7.2
- Qes 0.26
- Qts 0.25
- BL T/m 22.7 T/m
- MMS (grms) 58 grams
- Xmax (mm) 4.4 mm
- Sd 530 cm²
- Efficiency % 4.1%
- EBP 246
- Nett Weight 10.61 KG
- Gross Weight 11.48 KG
- Packing Size 34*35*19 CM
