ELECTRO ACOUSTIC SPECIFICATIONS
Nominal Chassis Diameter : 21/535 in/mm
MAX Power : 5000 Watts
RMS Power : 2500 Watts
Impedance : 4 Ohm
Resonance(natural) Frequency : 35 Hz
Frequency Response : 35-1000 Hz
Sensitivity(1W/1m) : 99 dB
Voice Coil Diameter : 5.5"/140mm
Winding material : PSV(inside-outside)
Magnet : 442 Oz // 330X170X22mm(2pcs)
THIELE SMALL PARAMETERS
FS Hz : 35 Hz
Vas : 165 L
RE Ohms : 3.6 ohm
Qms : 8.2
Qes : 0.22
Qts : 0.21
BL T/m : 42.7 T/m
MMS(gms) : 502 grams
Xmax(mm) : 8.6 mm
Sd : 1734 cm²
Efficiency % : 3.2 %
EBP : 159
Nominal Chassis Diameter : 21/535 in/mm
MAX Power : 5000 Watts
RMS Power : 2500 Watts
Impedance : 4 Ohm
Resonance(natural) Frequency : 35 Hz
Frequency Response : 35-1000 Hz
Sensitivity(1W/1m) : 99 dB
Voice Coil Diameter : 5.5"/140mm
Winding material : PSV(inside-outside)
Magnet : 442 Oz // 330X170X22mm(2pcs)
THIELE SMALL PARAMETERS
FS Hz : 35 Hz
Vas : 165 L
RE Ohms : 3.6 ohm
Qms : 8.2
Qes : 0.22
Qts : 0.21
BL T/m : 42.7 T/m
MMS(gms) : 502 grams
Xmax(mm) : 8.6 mm
Sd : 1734 cm²
Efficiency % : 3.2 %
EBP : 159
