Electro Acoustic Specification
- Nominal Chassis Diameter 18/460 in/mm
- Maximal Power 4000 Watts
- RMS Power 2000Watts
- Impedance 8 ohm
- Resonance(natural) Frequency 32 Hz
- Frequency Response 32-1500 Hz
- Sensitivity(1 W/1 m) 98 dB
- Voice Coil Diameter 5.5"/140 mm
- Windling material PI (inside-outside)
- Magnet 309 Oz
Thiele Small Parameters
- FS Hz 32 Hz
- Vas 114 L
- RE Ohms 6.2 ohm
- Qms 12.9
- Qes 0.27
- Qts 0.26
- BL T/m 41.3 T/m
- MMS (grms) 301 grams
- Xmax (mm) 8.6 mm
- Sd 12 mM
- Efficiency % 2.5%
- EBP 118
- Nett Weight 25 KG
- Gross Weight 28.30 KG
- Packing Size 51*51*29 CM
- Nominal Chassis Diameter 18/460 in/mm
- Maximal Power 4000 Watts
- RMS Power 2000Watts
- Impedance 8 ohm
- Resonance(natural) Frequency 32 Hz
- Frequency Response 32-1500 Hz
- Sensitivity(1 W/1 m) 98 dB
- Voice Coil Diameter 5.5"/140 mm
- Windling material PI (inside-outside)
- Magnet 309 Oz
Thiele Small Parameters
- FS Hz 32 Hz
- Vas 114 L
- RE Ohms 6.2 ohm
- Qms 12.9
- Qes 0.27
- Qts 0.26
- BL T/m 41.3 T/m
- MMS (grms) 301 grams
- Xmax (mm) 8.6 mm
- Sd 12 mM
- Efficiency % 2.5%
- EBP 118
- Nett Weight 25 KG
- Gross Weight 28.30 KG
- Packing Size 51*51*29 CM
