Electro Acoustic Specifications
- Nominal Chassis Diameter : 5/127 in/mm
- Maximal Power : 60 WATT
- RMS Power : 120 WATT
- Resonance(natural) Frequency : 68 Hz
- Rated Impedance : 8 OHM
- Sensitivity (1w/1m) : 92 dB
- Frequency Response : 68-9000 Hz
- Voice Coil Diameter : 1.5”/38.6 mm
- Winding Material : SV
- Magnet : 20 Oz
Thiele Small Parameters
- FS Hz : 68 Hz
- Vas : 4.6 dm3
- Re Ohms : 8 ohm
- Qms : 4.7
- Qes : 0.35
- Qts : 0.33
- BL T/m : 8.2 T/m
- MMS(grms) : 10 Grams
- Xmax(mm) : 3.5 mm
- Sd : 78 cm2
- Efficiency % : 0.4%
- EBP : 194
- Nett Weight : 1.58 KG
- Gross Weight : 1.69 KG
- Packing Size : 14.5*14.5*8 CM
- Nominal Chassis Diameter : 5/127 in/mm
- Maximal Power : 60 WATT
- RMS Power : 120 WATT
- Resonance(natural) Frequency : 68 Hz
- Rated Impedance : 8 OHM
- Sensitivity (1w/1m) : 92 dB
- Frequency Response : 68-9000 Hz
- Voice Coil Diameter : 1.5”/38.6 mm
- Winding Material : SV
- Magnet : 20 Oz
Thiele Small Parameters
- FS Hz : 68 Hz
- Vas : 4.6 dm3
- Re Ohms : 8 ohm
- Qms : 4.7
- Qes : 0.35
- Qts : 0.33
- BL T/m : 8.2 T/m
- MMS(grms) : 10 Grams
- Xmax(mm) : 3.5 mm
- Sd : 78 cm2
- Efficiency % : 0.4%
- EBP : 194
- Nett Weight : 1.58 KG
- Gross Weight : 1.69 KG
- Packing Size : 14.5*14.5*8 CM
